5T1007

FITS - LB225

Replaces - K001507 & K001520

Pad Size - Width: 248mm / Height: 110mm

All dimensions are measured from hole centre to hole centre. Counterbored holes highlighted yellow.

1 = 286mm / 2 = 400mm M20 x 2.5
3 = 378mm M20 x 2.5 / 4 = 290mm M20 x 2.5

Note:

Manufacturer's and other wholesaler's part numbers used in this catalogue are for cross reference purposes only and do not imply anything about the origin or manufacturer of the product.

If you have any questions relating to this product please contact technical@meibrakes.com
